The Corrugated Board Making Machine features a long, modular machine frame constructed of welded steel and sprayed with anti-corrosion paint. The machine consists of a reel unwinder, preheater, corrugating area, gluing and laminating area, shaping and drying section, slitting, and stacking/discharging. Equipped with an electrical control cabinet, servo tension control, and a safety shield, it is a complete industrial line for the continuous production of single- or multi-layer corrugated cardboard.

Features of the Corrugated Board Making Machine

High Production Capability - Continuous High-Speed Production

Under stable operating conditions, the Corrugated Board Making Machine can achieve production speeds of 120–260 m/min and accommodates paper widths up to 2500 mm. High-speed gears or servo synchronous drives ensure stable output, making it suitable for daily or weekly high-volume orders, significantly improving production line throughput and delivery capabilities.

Precision Forming - Corrugated Waveform and Lamination Accuracy

The Corrugated Board Making Machine supports various corrugated paper types, including A, B, C, and E, with wave forming accuracy within ±0.15 mm. Lamination temperature and pressure can be independently adjusted, and glue application accuracy reaches ±0.02 g/m². The finished board is smooth, with high bond strength, preventing delamination and warping.

Multi-layer Compatibility - Compatible with a variety of paper grades and thicknesses

The Corrugated Board Making Machine can process face paper weights ranging from 80–350 g/m² and core paper from 60–250 g/m². It supports single-corrugated, double-corrugated, and three-layer composite structures, with a paperboard thickness range of 1.5–12 mm, meeting the diverse strength requirements of e-commerce boxes, home appliance boxes, and industrial transport boxes.

Intelligent Linkage - PLC + Servo and Recipe Management

The Corrugated Board Making Machine utilizes a Siemens/Mitsubishi PLC + servo drive, featuring automatic tension adjustment, speed linkage, and recipe storage. Multiple process recipes can be preset, allowing for one-click switching between production lines. This reduces commissioning time and improves first-pass yield, facilitating flexible production of multiple varieties and small batches.

Energy Saving and Environmental Protection – Heat Recovery and Waste Reuse

The main motor power ranges from 70–160 kW, and is equipped with a heat recovery system in the drying section and a waste edge shredding system. This reduces energy consumption by 12–20% compared to traditional linear machines. It also supports waste recycling and reprocessing, meeting the green production requirements of modern factories.

Easy Maintenance – Modular Quick-Change and Remote Diagnostics

The modular design of key components allows for quick replacement of corrugating rollers, blades, and drive shafts, keeping routine maintenance and replacement time to 20–40 minutes. A remote diagnostic interface is provided for easy troubleshooting and software upgrades by the manufacturer or supplier, minimizing downtime.

Safety and Reliability – Comprehensive Protection and Certification Support

The Corrugated Board Making Machine features a transparent protective cover, emergency stop switch, safety interlock, and overload protection, complying with CE, ISO, and other industrial safety standards. Electrical components and grounding systems are arranged in strict accordance with international standards, ensuring operator and equipment safety.

Corrugated Board Making Machine Applications

Large-Scale Packaging Manufacturing Plants

This machine is suitable for producing large quantities of corrugated cardboard for retail and industrial customers. These plants require stable production capacity and line reliability. The Corrugated Board Making Machine provides continuous high-speed processing, helping companies like Smurfit Kappa expand production capacity, shorten delivery times, and reduce unit costs.

E-commerce and Fulfillment Packaging Suppliers

E-commerce packaging emphasizes multiple specifications and rapid changeovers. The Corrugated Board Making Machine supports rapid process recipe recall and mold changes, enabling it to provide custom-made boxes for fulfillment providers like Amazon FBA, improving shipping response time and packaging protection.

Food and Beverage Packaging Companies

Food packaging requires flat cardboard and compatibility with hygienic inks. Through precise forming and stable glue spraying, the Corrugated Board Making Machine produces cartons that meet food supply chain transportation standards, making it suitable for providing outer boxes and shipping packaging for Nestlé's supply chain products.

Home Appliance and Furniture Export Packaging

Large home appliances and furniture require high levels of compression and vibration resistance in their packaging. The Corrugated Board Making Machine can produce multi-layer composite corrugated board and custom reinforced boxes, meeting the stringent packaging strength and dimensional stability requirements of brands like IKEA and Haier during export transportation.

Pharmaceutical and Precision Electronics Packaging

Pharmaceutical and electronic products require packaging that is moisture-resistant, cushioning, and precisely dimensioned. The Corrugated Board Making Machine, through controlled temperature and precision lamination, produces highly flat protective boxes and inner trays suitable for Pfizer's pharmaceutical packaging and Foxconn's precision electronics logistics packaging.

Recycled and Environmentally Friendly Paper

Designed for environmentally friendly production lines using recycled fiber as raw material, the Corrugated Board Making Machine is compatible with recycled pulp grades and optimizes waste recycling processes, making it suitable for collaborative deployment in circular economy and sustainable packaging projects with companies like Mondi and Nine Dragons.
